Carbon black granulation equipment
1.The size of carbon black pellet is adjustable,the particle conversion rate is 100%.
2.The whole process in sealed condition. Equip with unique drying equipment and sealing device. No dust leakage,high environmental protection degree.
3.Computer programmed control conveying ratio, easy to operate.
4.Continuous production, electronic quantitative packing, save labor cost.
1.Carbon black powder be transported to the quota feeder by the conveying screw at the bottom of the silo
2.The quantitative feeder is controlled by computer. The feeder adjust the ratio of water and carbon black, put it into the granulator.
3.After the mixing and kneading of granulator,the carbon black particles form, put the particle into drying machine by bucket elevator to dry.
4.The carbon black pellet after dry was send to silo by bucket elevator to Weighing and packaging.
5.The dust produced by dry is collect by dust collector,the dust is send to carbon black silo.
Item | Type | THZL--24 |
Capacity | 1-1.5T/h |
Mode of production | Wet granulation |
Power consumption | 55kw |
Total power | 100kw |
Enter size | 330µm |
Exit size | 10-100µm |
Working pressure | Normal pressure |
Size | 5000mm(L)x1500mm(W)x1500mm(H) |
Floor space | 20000x6000 |
Highest point of installation | 7000 |
Labor | 2-3人 |
